FOR-X TX-50NEO

FOR-X TX-50NEO

1 299,00 kr

TESTED 20201010
Fs: 3000hz
Effective range 3800-20000hz
SPL 1w/1m 102dB
Wrms with hipassfilter: 200
Recommended filter normal 8000hz 6dB Capacitor 4.7uf
Screaming doors 8000hz 12dB Capacitor 2.7uf inductor 0,15mh

SPECIFICATIONS

General Data
Overall Dimensions: 100*82mm
Nominal Power Handling: 225 W
Transient Power 10ms: 450 W
Sensitivity: 105 dB
Frequency Response: 3k-20k Hz
Dome Material: Aluminum
Net Weight: 0.84 kg

Electrical Data
Nominal Impedence: 4 Ohm
DC Resistance: 3.6 Ohm

Voice Coil and Magnet Parameters
Voice Coil Diameter: 44.4 mm
Voice Coil Height: 3 mm
HE Magnetic Gap Height: 8 mm
Max Linear Excursion: –
Voice Coil bobbin: Kapton
Voice Coil Wire: CCAR
Number Of Layers: 1 L
Magnet System Type: Neodymium

T-S Parameters
Resonant Frequency: 3K Hz

Artikelnr: e31977a22916 Kategorier: , Varumärke:

Säljes i par.
450 Watt
225 Watt RMS
105dB
1.75″ Voice Coil
Impedance 4 Ohms
Frequency Response 3khz-220khz
Magnet Neodymium
With Crossover
A clean signal is a must, we recommend using AB amps.
