1 379,00 kr
100W RMS
200W MAX
Fs: 162hz
Effective range 160-8500hz
Impedance 4 OHM
Cone Material : Paper
Net Weight : 2.45 kg
Mounting depth 82mm
Overall Dimensions 174*92 mm
Nominal Power Handling 100 W
Transient Power 10ms 200 W
Cone Material paper
Net Weight 2,45 kg
Voice Coil Diameter 38,6 mm
Voice Coil Height 8,4 mm
HE Magnetic Gap Height 6 mm
Max.Linear Excursion 1,2 mm
Voice Coil bobbin Kapton
Voice Coil Wire CCAW
Number Of Layers 2 layers
Magnet System Type High Flux Ferrite
BL Product 7,1 N.A
T-S Parameters
Suspension Compliance Cms 0,086
Mechanical Q Factor Qms 3,9
Electrical Q Factor Qes 0,67
Total Q Factor Qts 0,57
Moving Mass Mms 9,95
Eq.Cas Air Load( liters) VAS 1,97 Liter
Effective Piston Area SD 126,6 cm²
TESTED 20201121
Break in: Yes
Fs: 162hz
Effective range 160-8500hz
On axis: 160-8500hz
Out of axis 45: 170-4900hz
Power pink noise >70hz/12dB wrms
Power pink noise >90hz/12dB wrms
Recommended filter general use >150hz 18dB
1w/1m Sensitivity 95dB
Component feeling a lot volume of enclosure: No
Optimal sealed volume: 4 liter
Loud mid crisp/clean
GALLER INGÅR
